XH-12KW/32KWH Solar Energy Storage System | 32 kWh Home Energy Storage

XH-12KW/32KWH Solar Energy Storage System | 32 kWh Home Energy Storage

$2,458.00
$2,458.00
Sale Sold out
Shipping calculated at checkout.
 Place of Origin:  China
                                      Battery
 Nominal Battery Voltage： 51.2VDC
 Rated Energy：32KWh (0.5C,25°C)
 usable Energy(90%D0D)：29KWh
 Max.Charge/Discharge Current：200A/200A
 Operation Voltage Range： 44.8Vdc ~ 58.4Vdc
 Operation Temperature： 10°C~+50°C
                                      Charger(PV+AC)
 Solar Charger Type：        DualMPPTs
 Max PV Input current /power：     1*MPPT:27A/9KW,2*MPPTs:22.5A/15kW
 Operating Voltage Range (VDC)：   90~485
  Max Pv Open Circuit Voltage (VDC)：      500
 Max Pv charge voltage(A)：      160
 MaxACCharge Current(A)：160
 Max.Charge Current(Pv+AC)(A)： 160
                                    DIMENSION
 Products size, mm：    695*295*1545mm
 package size, mm)： 855*480*1630mm
 Kgweight(Nw Kg)：    267kg
 Kgweight(Gw Kg)：     295Kg
                                AC Input
 Rated Input voltage(VAC)：   220/230/240; L+N+ PE
 voltage Range(VAc)：   90~280+3 (normal mode);170~280+3 (UPS mode)
 Frequency(Hz)：   50Hz / 60Hz (Auto Detection)
                                AC Output
 Rated Capacity (W)：12000W
 surge Power (VA)： 24000VA
 voltage(vAC)： 220/230/240
 Power Factor (PF)： 1
 Frequency(Hz)： 50/60Hz+0.1%
 Switch Time (ms)：10 (APP/UPS mode) ; 20 (GEN mode)
 wave Form：Pure Sine Wave
 Overload Protectionl：
  1.(105% < load <l10%) 5%: report error and turn off the output after 5 minutes
  2.(110% < load < 125%) 5%: report error and turn off the output after 10 seconds;
  3.Load >125% 5%: report error and turn off the output after 5 seconds
 Max.Efficiency(Battery Mode)：94%@48VDC
                                  General Protection
 Operating Protection：   IP20
 Operating Temperature：   -10°C~50°C
 Relative Humidity：   5% ~95% (Non-condensing)
 Storage Temperature：   -15°C ~60°C
 Max Operating Altitude：   4000m (Derating above 1000m)
                                  Interface
 reveal：   LCD
 communication：RS485/ RS232/ USB / Dry Contact
 Monitoring：   WIFI
View full details
1 3
Description
 Place of Origin:  China
                                      Battery
 Nominal Battery Voltage： 51.2VDC
 Rated Energy：32KWh (0.5C,25°C)
 usable Energy(90%D0D)：29KWh
 Max.Charge/Discharge Current：200A/200A
 Operation Voltage Range： 44.8Vdc ~ 58.4Vdc
 Operation Temperature： 10°C~+50°C
                                      Charger(PV+AC)
 Solar Charger Type：        DualMPPTs
 Max PV Input current /power：     1*MPPT:27A/9KW,2*MPPTs:22.5A/15kW
 Operating Voltage Range (VDC)：   90~485
  Max Pv Open Circuit Voltage (VDC)：      500
 Max Pv charge voltage(A)：      160
 MaxACCharge Current(A)：160
 Max.Charge Current(Pv+AC)(A)： 160
                                    DIMENSION
 Products size, mm：    695*295*1545mm
 package size, mm)： 855*480*1630mm
 Kgweight(Nw Kg)：    267kg
 Kgweight(Gw Kg)：     295Kg
                                AC Input
 Rated Input voltage(VAC)：   220/230/240; L+N+ PE
 voltage Range(VAc)：   90~280+3 (normal mode);170~280+3 (UPS mode)
 Frequency(Hz)：   50Hz / 60Hz (Auto Detection)
                                AC Output
 Rated Capacity (W)：12000W
 surge Power (VA)： 24000VA
 voltage(vAC)： 220/230/240
 Power Factor (PF)： 1
 Frequency(Hz)： 50/60Hz+0.1%
 Switch Time (ms)：10 (APP/UPS mode) ; 20 (GEN mode)
 wave Form：Pure Sine Wave
 Overload Protectionl：
  1.(105% < load <l10%) 5%: report error and turn off the output after 5 minutes
  2.(110% < load < 125%) 5%: report error and turn off the output after 10 seconds;
  3.Load >125% 5%: report error and turn off the output after 5 seconds
 Max.Efficiency(Battery Mode)：94%@48VDC
                                  General Protection
 Operating Protection：   IP20
 Operating Temperature：   -10°C~50°C
 Relative Humidity：   5% ~95% (Non-condensing)
 Storage Temperature：   -15°C ~60°C
 Max Operating Altitude：   4000m (Derating above 1000m)
                                  Interface
 reveal：   LCD
 communication：RS485/ RS232/ USB / Dry Contact
 Monitoring：   WIFI
